Kinarfi

Recommended Posts


Dealers - - - also see http://www.utvboard....dpost__p__16044 & http://www.utvboard....dpost__p__16045
No Limits Powersports in Arlington Texas - Contact Jarrad (Snowman6479). (817)695-1151 http://www.joyner-atv-utv.com/
Silver Bullet Motorsports in Yuma Arizona - Contact (silverbullet). (928) 344-2117 http://www.silverbul...otorsports.net/
Thin Air Powersports in Spring Creek Nevada - Contacts Tim (Anylizer) or Amanda (Long Track Lady) (775)753-8223 http://www.thinairpowersports.com/
McCoy Motorsports in Pikeville Kentucky - Contact Art (Art) (606)432-1556 http://www.tobefast....sa-c-63727.html
Mudslingers Motorsports, Alberta, Canada, Trevor Carson (780) 576-2860 cell: (780) 984-2711 http://www.mudslinge...website_006.htm
Joyner USA In Phoenix Arizona - Contact Brandon Deruiter Office (480) 882-9612  Email [email protected]   Web site Joyner-usa.com


I also take suggestions for any and everyone!!

parts & pieces from dealer in Germany

http://www.utvboard.com/topic/3168-joyner-parts-and-all-chery-and-lj276-engine-parts/?p=18349

AIR FILTER K&N RU-1000, RC-4160, and another link
If you have the new 09 filter box, w/ Fram # CA-7764
ALTERNATOR BELT 14mmx 755mm replacement that works....Carquest #K040292
Alternator Belt - Checkers Auto Parts KO40292 - Exact Match
Battery, according to 2 scoops, Duralast 51-DL is the correct size.
OIL FILTERS
Troopers with Thread Size 20X1.5 MM can use:
WIX 51347, 51334 --- Napa 1347, 1334, PS1334 --- Fram PH6010A, PH3593A
Troopers with Thread Size 3/4X16 " can use:
Fram PH4967, Napa 1394 & Wix 5194 (slightly longer than original, Wix 51396 (even longer yet).

OIL COOLER See thread, http://www.utvboard....768-oil-cooler/

Oil Pressure Gauge Replacement
Zorro found some at his Local Marine Supply store
Sending Unit -- TeleFlex Morse Part # IA15001 0-80 psi, 240-33 ohm
Gauge -- TeleFlex Morse Part # 57903P 0-80 psi, 240-33 ohm
Manufactured by Veethree Elec. & Marine LLC
together cost aprox $80.00
Says it fits the existing hole perfectly Thanks Zorro
Plumber added this reference; http://www.spydertal...pressure-gauge/ which Crosses over to a Sierra part# 01858990
IMHO--I would move the the sender away from the exhaust manifold.

FUEL FILTER replacement, Fram Fuel Filter G4777

FUEL PUMP replacement, Bosch 0 580 254 910 According to Brostar, (Thank You!!)
http://www.ebay.com/itm/Hayg-OEM-Inline-Fuel-Pump-0-580-254-910-0580254910-New-/230568738342#vi-content (updated 05-2015)

PRE FILTER KNN-RC-4160-DK prefilter

HEAD LIGHT REPLACEMENT Sylvania H5006 replaces the whole bulb, It works sooooo much better than the original.

SPARK PLUGS NGK Iridium BKR5EIX-11, NGK 2387, NGK BKR7ES-11, Bosh 3311, Denso Iridium plug 5310 IK22

CV Boot Kit There appears to be a difference between inner and outer boots, I used a NAPA CVB6862340 for my outer rear, fit good but not tightly on the CV end, I held it on with Tyraps
Autozone part # 03606. Comes with bands and grease for $11.99, quick/split boot. K2181 95 Geo Metro $15.99
NAPA #686-2149 fits for the Troopers inner CV. It's a speck tight but only about 1/16".(Lenny)
Napa 686-2181 CV Boot from a 95 Geo Metro.
http://www.norrecind...tart=1&cat=1394 or
Norrec Industries then Application, then UTV, then look up joyner, they have them all
Polaris CV Boot Kit # 2203438, (PR-8061)
Also see CV boot for driveline? - UTV BOARD - Side X Side and UTV Forum

Valves shims are 25mm, Joyner shims start at 2.18 and increase in increments of .02 up to 2.80, The Honda shims come out of CB450s and GL1100s, start at 2.30 and increase in increments of .05
http://www.mawonline...gle/P137630.HTM
http://stores.ebay.c...&_sid=120606839

Master Electrical Switch Key
http://www.jegs.com/...oductId=1231908
http://www.pegasusau....asp?RecID=1467
Make your own, it's easy, I did, just in case mine breaks.

At the suggestion of one of our members, here's some info on the gas gauge sending unit.
3 ohms is full, 13 ohms is 3/4, 23 ohms is 1/2, 63 ohm is 1/2, 110 ohms is empty.
Electrical readings are: F=0.75v-98ma, 3/4=1.91v-82ma, 1/2=2.7v-71ma, 1/4=3.3v-62ma, 0=4.1v-52ma, E=5.0v-39ma
0 is top of red zone, E is bottom of red zone.


Manuals and Information


Trooper T2 weights, 380lb. on each front wheel, 480 lb. on left rear, 520 on right rear TOTAL = 1760 pounds

down load this and save it!!!!
Torque Values Select Your type of bolt at the top. http://www.engineers...bles/torque.htm
My Snorkel Made from a Sears ShopVac 7' Hose and the Extension Wand,


Oil Drain QuickOilDrainValve.com

http://www.oildrainvalve.net/ez-oil-drain-valve-ez-103-12mm-1-25/

the best way to change oil, IMHO Kinarfi
Fram Sure Drain #SD3

Paint as recommended by Brostar: http://www.zynolyte..../rustmaster.asp

Supplier of parts in General

http://www.cxracing.com/default.aspx
http://www.jegs.com/
http://www.summitracing.com/
Pegasus Auto Racing Supplies - Home Page
TireRack.com
McMaster-Carr
Discount Hydraulic Hose.com

Tie Rod Dust Boot, Checker Auto#13566

Rod End / Heim Joint Seals , http://pitstopusa.co...-end-seals.html, thanks rocmoc
Ball Joint Rod Ends AKA Heim Joints
16 x2.0mm threat, 16mm ID, 21 mm thick,
I got mine at McMaster-Carr 4483T36
PTFE/Kevlar Insert, M16 x 2.0 x 40.mm shank, 21,966 lb static radial load capacity, 23°, $25.60 ea. or $204.80 for 8
http://www.vxb.com/page/bearings/PROD/Kit12360
http://www.vxb.com/page/bearings/PROD/Kit12960

14 Inch Tires That fit our Stock Wheels Note that the stock lug bolt pattern is 4 X 115
STEEL WHEELS http://www.utvboard....dpost__p__10804
JC Whitney for all Auto parts - Car, Truck, Jeep, Motorcycle & RV Parts
Interco Tires SSR-24R - INTERCO SSR Series Tire - Quadratec
Interco Tires SAM-12 - INTERCO Super Swamper TSL Tire - Quadratec
TSL Radial | Interco Tire
Maxxis Bighorn 2.0 AT26 X 11R 14
General Grabber AT2 27x8.50 R14 95Q 6PR OWL $90.10 http://ssl.delti.com.../GRABBERAT2.jpg
National Chaparral A/P 27x8.50 R14 95Q 6PR OWL $113.80 http://ssl.delti.com...ChaparralAP.jpg
Kumho Road Venture MT-834 27x8.50 R14 95Q 6PR OWL $110.30
Mastercraft COURSER A/T 27x8.50 R14 95Q 6PR OWL $87.00 http://ssl.delti.com...t/COURSERAT.jpg
Cooper Discoverer LT 27x8.50 R14 95Q 6PR OWL $99.60 http://ssl.delti.com...iscovererlt.jpg
Laramie Performer RV 27x8.50 R14 95Q 6PR OWL $100.70 http://ssl.delti.com...PerformerRV.jpg
ITP MUD LITE XTR 27-9-14 $87.99
ITP TERRACROSS R/T 26-9-14 $144.99

15 inch Wheels [Be sure to get the correct lug nuts, 12X1.5
Vision Wheel Inc Vision Wheel
ITP has one now also, getting info. ITP TIRES - The World's #1 ATV Aftermarket Tire & Wheel Source :: Holeshot

Non Trooper Info
u joints for joyner renegade are Spicer 5-1501X and Precision 391. They are American work great. graybeard9

Differential Bolts

40 28 to Full 25 96144A227 8.33

1100 Trooper T2 ECU Wiring Diagram.pdf

Diff Ring Bolt.png



Joyner Trooper Differential Rebuild Kit .doc

  • Like 1
Link to comment
Share on other sites

  • 2 years later...

How to change the Rear Wheel Bearings - By Rocmoc.

You will need -

Two rear wheel bearings, I got mine from snowman at No Limits Powersports, http://www.joyner-atv-utv.com/ but also available from Silver Bullet Motorsports, http://silverbulletmotorsports.net/ & http://www.jmcmotors.us/ Roller bearings

Two seals (metric sizing), part specs TC 45 65 8 purchased from Motion Industries, http://www.motionind...LocationsMI.jsp NOTE: Page 198 of the 2009 manual, page 183 of the 2008 manual,

says I need #3(03.06.13871-FB45×65× 13871-FB65X42X8 Seal FB65X42X8) and #32 (03.06.13871-FB45×65× 13871- FB65X45X8 Seal FB65X45X8) seals, but I know that the # 3 seals actually needs to be 62X42X8

Large socket set to break the nut loosen the axle holding the hub on. I have a 3/4" set and worked great.

C-clip removal tool, I have one but was easier using an old screwdriver trick.

Seal puller, I have a bodyman's dent removal tool with an adapter that works. This saves the old seal but you could use a screwdriver and kill the seal.

Remove the wheel/tire.

Remove the cotter key.

Remove large nut, someone needs sit in the Trooper applying the brakes to keep the axle from turning.

Remove the brake calipers, 2 bolts per caliper & two calipers per wheel in the rear for a total of 4 bolts.

Slide the hub & rotor off the end of the axle.

Remove the 2 bolts holding the backing hub/bearing housing to the swingarm. One on top, one on bottom.

Remove the bearing housing.

Wipe, clean so you can see what you are doing.

Remove the seal. The seal is in front of the C-clip & bearing.

Wipe, clean so you can see what you are doing.

Remove the C-clip, can be a pain if you have never done it before.

Slide the bearing out.

CLEAN!

That is as far as I am on one side. Waiting for the seals. Why there are seals is beyond me. The bearing is sealed so it is just extra protection. There was grease in the area between the seal & bearing. Cheap insurance so I will put it back the way I found it. I can tell the bearing has spun a very very small amount. The fit between the housing & the bearing is still very very good. Lenny's tip to locite the outside of the bearing in place to the housing is important! But will make it more difficult to remove the bearing the next time it requires replacement.

Yes, my original bearing had wear & slop. IMHO not that bad but did need replacement. The bearing isn't as bad as the design of the housing is. Taper roller bearings should have been the real design but what the heck lasted 4 years.

If you see anything that needs correction, please post it as a reply. I'll take note, fix, and delete your post.

  • Like 1
Link to comment
Share on other sites

  • 4 weeks later...
  • 7 months later...

650 Sand Spiders (two cylinder models) with Thread Size 3/4X16 " can use:

STP S3614

Oil filter for the 650 Sand Spider - STP S3614 will fit without hitting the frame rail. The crossover in the Fram brand is too long, so although a PH 3614 looks as though it should fit, it won't clear the frame.

You may have to loosen the motor mount nuts (14 mm wrench) to jimmy the engine up high enough to install the filter. I had to take the nuts clear off to jimmy the engine high enough to get the Fram filter in there, but then the end of the filter contacted the frame.

You can see how close it gets in the picture, and this is the STP filter.

The filter has a 3/4" thread, not the more common (for imports) 20 mm thread.


Link to comment
Share on other sites

  • 7 months later...

some additional info I cam across. Some of it is redundant to what we already have here, but thought I would put it out here.

Passenger diff seal, Car Quest part # 3655 size 51.9mm O.D. x 35mm I.D. Fits 1100, 800 EFI

Front wheel bearings - NSK 6205Z-2ZR-C3 and 6206Z-2ZR-C3, SKF or FAG 6205-2RSR and 6206-2RSR

Conversion to tapered roller bearings is possible with some hub modification - 30205A and 30206A

Rear wheel bearings - Peer FWD 305532, 6006 2RS and 3006 2RS

Conversion to tapered roller bearings is possible with some modification - 32006X

Front a-arm ball joint - GE25ES 2RS

Oil filter - Mann W67/81, China SPC932, Bosch O 004

Brake pads - EBC FA482TT - tried to find these, but unable to get through an american vendor. ordered sets of FA473V to try out. Will follow up with full post when I get them in and try them out

Tachometer w/ temperature gauge - Koso GP-Style (55mm, 0-9,000 RPM)

Arctic Cat quads use the same hubs as the 650 Joyner so the brakes will also work from Arctic Cat. Others have found Wilwood brakes that fit the 650. These parts do not fit the 800cc and larger buggies

The Geo Metro and Suzuki Swift 3-cylinder 1-liter engine will fit the 800cc chassis with minimum modification

inner cv boots off a 1998 Geo Metro. They only cost $10 each instead of the $20 to $30 at a off road shop and available at any auto store! Fits 1100, other models not too sure

source: http://www.joynerfor...-Need-your-help!

Want to add, I have not verified this. Thats up to anyone who may need a listed item. But if anyone does verify via use of any of the listed items, please let us know!

  • Like 1
Link to comment
Share on other sites

  • 3 months later...

If you need a reverse switch use this one 96 Geo Metro reverse switch 1.0 Same threads same gasket same lengh...Ordered it from Rockauto...12.00 bucks with shipping. Anyways it takes care of 2 things it is a sealed unit with wires attached no dirt in it and I soldered the wires togather on mine so 1 less plug to worry about. Works well.....Hope this helps someone out there....

Link to comment
Share on other sites

Replacement Headlights I used are Sylvania H5006 High/Low. I would imaging the number is the same for any manufacturer. The Headlight sockets to change it over are Dorman 9003 High Temps.....

Edit by Kinarfi, I just soldered leads to the lugs and used my own connectors, but the H5006 Lamps fit good.

Link to comment
Share on other sites

  • 1 month later...

Current Dealer list:

Go Karts USA

2121 North California Blvd

Walnut Creek, CA 94596

925-906-0330

www.gokartsusa.com

Supersportz

7209 Arlington Ave. #A

Riverside, CA 92503

951-662-3828

www.supersportz.com

Advantage motorsport

885 West Wickenburg Way

Wickenburg, AZ 85390

(928) 684-2522

PBO Auto Sales

3842 East Roeser Road

Phoenix, AZ 85040

(602) 828-1885

Fun Share RV

2583 Highway 6 and 50,

Grand Junction, CO 81501

970-241-2702

www.funshares.com

Audio 2000

4742 East Speedway Boulevard

Tucson, AZ 85712(520) 624-2000 ‎tucsoncaraudio.net

Beavers Construction

580-320-3053

Shop address:

1038 state hy 99 n

Ada, ok 74820

NFR Auto Sales and ATV

10 Shaft Rd

Hazelton, PA 18201

570-459-2272

Lems Auto Sales

2337 Hoey Church Road

Shelby, NC 28152

704-484-3451

www.lemsautosales.com

Link to comment
Share on other sites

The below are Service ONLY Dealers:

Four brothers ATV

724-727-7830

4903 RT 66

Apollo, PA 15613

Bulldog Motorsports

48163 Taylor Rd

Roger, Ohio 44455

330-227-9188

Mudslinger

313 Shawnee Ave

Big stone gap, VA 24219

276-393-2860

SYC Powersports

468 Christian College Rd,

Senatobia, MS 38668

662-301-1563 Tom

www.sycpowersports.com

No limit Powersport

2925 East Division Street,

Arlington, TX

(817) 695-1151

www.joyner-atv-utv.com

Oasis marine

3382 E Holladay

Tucson, AZ 85706

(520) 293-4041

Woody's Performance

405 W Main St

Tonto National Forest

Payson, AZ

Unleashed Motorsport

781 Air Park Way

Cottonwood, AZ 86326

Silver Bullet

928-344-2117

2811 S Avenue 2 1/2 E

Yuma, AZ

Berts Mega Mall

1151 North Azusa Avenue

Covina, CA 91722

Emrock ATV

775-856-3398

320 S Rock Blvd,

Reno, NV

Thin Air Powrsports

775-753-8223

1169 Solar W Dr

Spring Creek, NV

http://www.thinair-usa.com/

Link to comment
Share on other sites

  • 2 months later...
  • 4 months later...

Idle Air Control (IAC) for the Chery 1100:

Freewai.com

A: D5148 round head for DA465 1.1L, some SQR372 0.8L, siemens system

I chose the "excellent" type, but you can also select the genuine part. It was $17 plus $30 shipping. It was this or $209 for a throttle body from one of the stateside vendors. They don't sell the components separately. Freewai was an excellent company to deal with and it arrived in 5 days.

Link to comment
Share on other sites

  • 2 weeks later...

For the starter solenoid you can use a 96 Geo Tracker.. Replaced my solenoid with one. Bolted right up... 1.6 GEO motor ..Make sure you check it out before buying for the starter motor part. I do not know if it spins CW or CCW plus I did not count the teeth on bendix. The solenoid is 78.00 at Advance.. 25.00 For used starter at junk yard.

Link to comment
Share on other sites

  • 4 months later...
  • 2 years later...
  • 1 month later...
  • 8 months later...
  • Kinarfi changed the title to Parts, Pieces, and Information for our Troopers & Joyners
  • 5 months later...
  • 2 weeks later...
How to change the Rear Wheel Bearings - By Rocmoc.
You will need -
Two rear wheel bearings, I got mine from snowman at No Limits Powersports, http://www.joyner-atv-utv.com/ but also available from Silver Bullet Motorsports, http://silverbulletmotorsports.net/ & http://www.jmcmotors.us/ Roller bearings
Two seals (metric sizing), part specs TC 45 65 8 purchased from Motion Industries, [url=]http://www.motionind...LocationsMI.jsp[/url] NOTE: Page 198 of the 2009 manual, page 183 of the 2008 manual,
says I need #3(03.06.13871-FB45×65× 13871-FB65X42X8 Seal FB65X42X8) and #32 (03.06.13871-FB45×65× 13871- FB65X45X8 Seal FB65X45X8) seals, but I know that the # 3 seals actually needs to be 62X42X8
Large socket set to break the nut loosen the axle holding the hub on. I have a 3/4" set and worked great.
C-clip removal tool, I have one but was easier using an old screwdriver trick.
Seal puller, I have a bodyman's dent removal tool with an adapter that works. This saves the old seal but you could use a screwdriver and kill the seal.
Remove the wheel/tire.
Remove the cotter key.
Remove large nut, someone needs sit in the Trooper applying the brakes to keep the axle from turning.
Remove the brake calipers, 2 bolts per caliper & two calipers per wheel in the rear for a total of 4 bolts.
Slide the hub & rotor off the end of the axle.
Remove the 2 bolts holding the backing hub/bearing housing to the swingarm. One on top, one on bottom.
Remove the bearing housing.
Wipe, clean so you can see what you are doing.
Remove the seal. The seal is in front of the C-clip & bearing.
Wipe, clean so you can see what you are doing.
Remove the C-clip, can be a pain if you have never done it before.
Slide the bearing out.
CLEAN!
That is as far as I am on one side. Waiting for the seals. Why there are seals is beyond me. The bearing is sealed so it is just extra protection. There was grease in the area between the seal & bearing. Cheap insurance so I will put it back the way I found it. I can tell the bearing has spun a very very small amount. The fit between the housing & the bearing is still very very good. Lenny's tip to locite the outside of the bearing in place to the housing is important! But will make it more difficult to remove the bearing the next time it requires replacement.
Yes, my original bearing had wear & slop. IMHO not that bad but did need replacement. The bearing isn't as bad as the design of the housing is. Taper roller bearings should have been the real design but what the heck lasted 4 years.
If you see anything that needs correction, please post it as a reply. I'll take note, fix, and delete your post.

Are the parts for the rear like bearings and seals the same for the front wheel bearings? And also are the wheel seals cross refrencable to a part you can get at the auto parts store?


Sent from my iPhone using Tapatalk
Link to comment
Share on other sites

  • 2 weeks later...

So I ordered a new cv axle for my trooper t2 1100 from Joyner they send me a completely different. Axle different color, diameter and length. It's atleast an inch longer than the one that came off it f67ab9856d218c4c73fed8c331c007a4.jpgf704721ee7151b0e26ff7b0995fdda47.jpgd3c4b0ea0ec536be267d1997e89191c8.jpg305b3ba3bb9aa2ab3d9f743dcd053c62.jpg
I've spoke with them multiple times on the phone. And email did not reply or call after leaving multiple messages. There telling my they change design and that I have to compress it for it to fit. Well it won't compress 3" also I order the wheel seal and as noted in the previous post 1 wheel seal is the wrong size so I tell them the correct dimension like mentioned before and they still sent me the wrong one. Are any of the parts replaceable. I'm pissed


Sent from my iPhone using Tapatalk

Link to comment
Share on other sites

  • 9 months later...
  • 3 months later...



1/26/2019

If your in need of Joyner parts get ahold of

 Casey Ye

My contact in China. Very reputable woman. Has parts in the states.

From Casey.

please help me to inform them that i Have ordered 20 pieces of 650 rear CV axles which will be available in beginging of April. if They want They Can contact me. I willconfirm exact available time after Chinese New Year Holiday. Thanks.

[email protected]

Have part numbers as she is a not associated with Joyner. Just gets us the parts we need.

Be cautious on part numbers because shipping is really high on China shipping of heavy parts and she is trying to make money and also support our Joyners for us.



Link to comment
Share on other sites

Join the conversation

You can post now and register later. If you have an account, sign in now to post with your account.
Note: Your post will require moderator approval before it will be visible.

Guest
Reply to this topic...

×   Pasted as rich text.   Paste as plain text instead

  Only 75 emoji are allowed.

×   Your link has been automatically embedded.   Display as a link instead

×   Your previous content has been restored.   Clear editor

×   You cannot paste images directly. Upload or insert images from URL.

  • Similar Topics

    • By mcraigchr
      I realize that many of you do not have diesel machines.  For those that do, this is for you:
      Just wanted to post my experience this past week.  Here in Texas, we had pretty good dip in temps.  For 4 days it did not get above 25.  At night, it was single digits or close to it.  I always put Sta-Bil fuel stabilizer in the storage tank (30 gallon).  And up until this tank I was using Power Service (white bottle) for anti-gel.  Never had an issue.
      This tank, however, I switched to Stabil All season (anti gel).  It is supposed to good down to -40.  Zap.  That is a big fat lie.  I put in twice the amount called for in the instructions.  Result was less than optimal.  I drove the SxS 100 feet (to go get the mail) and it died.  I looked at the fuel bowl and it was a cloudy, wax substance.  So, the Stabil did not work.  That said, I'm not sure that I ever tested the Power Service in the same manner.  So I am not saying that one is better than the other.
      What are your experiences?  Are these products inferior?  What do you folks in the northern states / Canada use?  Am I missing something?
      CC
    • By Jon Spruill
      Hey Guys, I have been chasing a stalling condition for about two weeks now. The bike will crank up and idle fine, then after about 20 seconds it will fall on its face and stall. It happens at both idle and while running at various rpms. You can turn the key off, turn it back on and it will fire right back up without trouble. I have verified spark on both cylinders with a spark tester. I have also added an inline fuel filter, and pulled the injectors to verify proper pulse on each. Things I have replaced - (relearn procedure performed after each component replaced): spark plugs, ECU, relay/fuse box, fuel pump, & throttle position sensor - all with no improvement of the condition. The only warning light I get when the condition occurs is the oil lamp. The bike only has 14 miles. I am at a loss and appreciate any help and suggestions! Thanks
    • By Dan_Lockwood
      If you pay any attention to your UT400, you have probably noticed that the right front wheel tips in at the top a LOT.  The left fronts seem to be about right from what I've seen.  I look at them all when I'm at different stores just to see if they're all that way, and yes, they all seem to be that way.
      There "should" be adjustments on either the ball joints or the inner pivot points, but these are solid, not way to adjust them.
      I have the UT400 up on my 2-post lift and the right spindle seems to be around 3-deg tipped in at the top and the left spindle is about straight or maybe half a degree tipped in.  This is at full suspension drop, not ride height.  I took the shocks off and rotated the spindles from bottom travel to full max up travel, way more than the shocks will allow.  The higher the spindle lift, the more tip in there is on both spindles.  This is true because of the unequal upper and lower A-arms.  It's just the nature of of the dual A-arms and them being unequal in length.
      I took the inner pivot 8mm bolts out and inserted a lot smaller 1/4" bolts and pushed the lower A-arm inward and the angle on the spindle decreased.  I then took the top inner bolts out and did the same thing, but pulled out instead.  This got the spindle equal to angle of camber on the left side.  I used the offset in the holes to see how much I need to go on the lower alone.  I was also concerned about bottoming out the axle assembly because the spindle centerline will not be a bit closer to the front diff.  But as it all turned out, it was not close to bottoming out.
      I cut about 1/4" out of the two 1" A-arm tubes as they were welded to the lower ball joint mount casting.  I tack welded them back together and trial fit it all together.  That seemed to be about right.  I took it all back apart and welded it up solid.  Now it all looks to match the left side quite well.
      Also want to use this in our yard and the stock tires are NOT turf friendly, especially with the solid "spool" rear differential.  I found these on Amazon, 25x12-12" and 25x8-12" hard pack race tires as they're called.  They're 6-ply and tubeless.  The initial probably I had was that the size rating was not even close to the actual size.  They said, install and then recheck the diameters and I did.  They did get larger, but the rears are more than 1" smaller in diameter than the side wall stamping.  Instead of 25", they're 23.75" tall.  What I DON'T WANT are shorter tires.  I had already purchased the used wheels at 12" to match the original factory diameter, but in hindsight I would now opt for 14" wheels with 4x110mm bolt pattern and would have been able to find a tire in the 27" diameter range a lot easier and cheaper.  Live and learn they say.
      Here are some pictures of before and after.










    • By Pablo
      Hi. Ive been searching for a wiring diagram, hopefully with photos, part #s so I can try to repair damage from rats eating wiring over the winter on the M550 cub cadet UTV. (sigh). haven't had any luck. i have a plug with dangling wires from under seat, next to battery compartment and hope to take to dealers to see if he can order replacement and hopefully it comes with long enough wires that i can splice back into remaining wires. not going to be easy. I'm not sure if there is any more damage, but would have to disassemble to get to bare chassis. sigh. not sure I can do all that, but just trying to find a diagram with photos. no luck. any ideas. thank you.
    • By Hisun .500
      So my hisun 500 is tore up and all the wiring is wasted i was wondering can i pull out all the wiring and just put in the. Basics .please help
×
×
  • Create New...
