What is the Kawasaki engine model number for the side by sides listed below. I had an older Ute with the 401cc Kawasaki FJ 400D, but it had a carburetor, and a flywheel magneto ignition system.
This new 401cc engine with EFI, and electronic ignition looks like a big improvement over the old. But, I can’t find the Kawasaki engine model number?
Kawasaki 401 cc (24.47 cu. in.) single cylinder, 4-stroke, gas
Bore x Stroke: 3.23x2.99 in
Compression Ratio: 8.6:1
Maximum Torque: 21.4 lb-ft @ 2400 rpm
Valve Train: Single-Cylinder OHV
Engine Vibration: Internal Counter Rotating Balance Shaft
Fuel System: Closed-loop electronic fuel injection
Horsepower (KW): 13.5 hp
Electrical System: Starter/Generator — Solid State Regulator
(Note: Some versions/listings state: "Alternator Output (max)22.9 amp")
Lubrication: Pressurized Oil System
Oil Filter: Spin-On (Item#: 49065-7010)
Cooling System: Air Cooled
Ignition System: Electronic Inductive Spark
Air Cleaner: Replaceable Dry Cartridge (item #: 11013-7029)
Utility vehicles/side by sides that use this engine:
2021MULE SX™ 4x4 FI
2020 E-Z-GO Express™ S4 Elite Gas
Cushman Shuttle 4 EFI Gas
Cushman Hauler 1200
Im new to the utv world. I just bought a 2014 Odes Raider 800. It has only 10.2 miles but has been sitting awhile. I want to change oil and front and rear differential oil. Cause it still has what ever they stuck in it from the dealership. Also what gas rating should I run in it. I figure mid or high test fuel. I downloaded the manual for it but it does not say what gear oils or or oil it runs. Thanks for any help and input.
By Grant Andrew Fralick
all im needing is to figure out where i go to find parts for this 4 wheeler?
i blew an axle and i cant find parts any where! very frustrating, all though i picked the bike up for $200 now i see why, is there part number or cross reference number. the thing and drives like a dream NO issues at all. i just really wish i could find a parts depot, hope you guys can help!!!!
Anyone have wiring diagrams for a 2013 dominator 800? I bought one at an auction that had some wires burned up. There's a 9 pin connector that completely burned up so I'm trying to match the wires back up and they aren't the same colors on each side. I believe it's the engine interface connector.
A wiring diagram or pics of that connector would be awesome. Any help would be appreciated.
