New to side by sides


Recommended Posts

  • 3 years later...

Join the conversation

You can post now and register later. If you have an account, sign in now to post with your account.
Note: Your post will require moderator approval before it will be visible.

Guest
Reply to this topic...

×   Pasted as rich text.   Paste as plain text instead

  Only 75 emoji are allowed.

×   Your link has been automatically embedded.   Display as a link instead

×   Your previous content has been restored.   Clear editor

×   You cannot paste images directly. Upload or insert images from URL.

  • Similar Topics

    • By AlphaSerenity
      Hello,
      Before I invest $10k+ into a brand new UTV for the farm, I want to get my feet wet with a fixer upper and learn the mechanical side of things. I acquired a 2022 Hisun Axis 500 (Lowes-specific model) from an auction for $500. It has only 200 hours and 120 miles on the engine. It looks like the previous owner used it for ranch work and didn't drive it on trails, deep water/mud, or anything too crazy.
      While it runs and moves, it has some problems. It struggles to accelerate up any incline in high and low range and sometimes stalls when I let off of the throttle or change gears. When I apply throttle in neutral, it sounds like it is struggling for fuel/air and pops. When I decelerate, there is a grinding sound coming from the clutch, which I've read to be related to the one way bearing and is semi-common. The last thing I've observed is sometimes the speedometer display sometimes will show a much higher value for a few seconds after barely touching the throttle. Based on the documentation, if a problem is detected from the sensors, the instrument panel display should have an error code rendered on the screen in place of the time, but this isn't happening. Here is a video showing some of these issues (engine is exposed with console removed):
      https://www.youtube.com/watch?v=FFAkO5TaGps

      Here is another video of the clutches in action:

      I've done some research, but information on this specific unit and sister units is limited. There does seem to be transmission and clutch issues reported. I still need to check into the head gaskets. I don't have the equipment to test compression right now, but I do plan on ordering what is needed soon. I do have an order in place for some cables to read the diagnostics from the computer. There is a shop two hours away from me that works on Hisun products, but I am hoping the problem can be identified and is something within my ability to handle. Below is what I've already investigated.  I am leaning towards the primary clutch needing replacement right now.
      After getting it home and unloaded, I did the following maintenance/checks to it prior to operating it further:
      Changed the engine/clutch oil (and filter) and gear oils using manufacture recommended viscosity Changed the air filter and checked for cracks in the air intake flow. Verified good suction. Cleaned the throttle body Changed the spark plug and verified the gap was within spec (0.6-0.7mm) Changed the coil and coil wire Changed the fuel lines, fuel injector, and verified the fuel pump was outputting the correct initial prime pressure for ignition and continuous pressure after ignition. Also completely emptied the fuel tank and made sure octane 91+ fuel is being used per manufacturer specs. Ran seafoam through system too. Cleaned the spark arrester and verified no cracks or gaps in the exhaust flow Changed out the O2 sensor Checked all wired connections to ensure they were secured and no breaks were visible Checked the belt for tightness and for any signs of wear and tear Verified 4WD and the differential lock function as expected - still hesitates and struggles uphill Verified the fan gears in the shifter are not corroded and working as expected ECU was reset after replacing sensors and fuel-related parts

      Thanks!
    • By Steve Toney
      Hello, my name is Steve and just signing up.  Bought my first UTV yesterday.  It is a Massimo T-Boss 550.
    • By SafeSledBryan
      Hey guys! My name is Bryan and i am the owner and creator of Safe Sled. Not some crazy corporate backed recovery product, but just some guy with an idea.

      4 years ago, I suffered 11 strokes, and am now 50% paralyzed on the left side of my body. I am unable to work a normal job anymore. I was working on the sled 2 years before this all unraveled. My wife told me to keep working on it since i was pissing her off staying home and doing nothing.
      I still plan on improving and implementing different ideas as the product’s revenue continues to grow.
      if the sled is appealing to you, please check out my website, safesledoffroad.com
      Safe Sled Website
    • By Bassarino51
      My 2014 Odes with less than 1000 miles suddenly won’t turn over with a fully charged battery.
    • By didgeridoo
      Hello, All!  I've decided to replace the traction batteries in my 2018 Sector E1 with a 48V Lithium set. They may be expensive, but I figure the Discovery Dry Cell are, too. I am not looking for the max driving range, as I have never received near the brochured range to begin with, but a good mix of charge/ get work done/ charge is what I am expecting.
      I have settled on the 48V EAGL kit from bigbattery dot com. Each battery pack provides 30Ah. The kit ships with a charger, as well. The packs would be physically connected in parallel (using a busbar) to one another, maintaining the 48V voltage, but together would be able to provide the amp draw the buggy pulls when going up hill or towing a rake (rated 320 max continuous Amps). This is in comparison to the serial connection the eight 6V lead batteries. Each of the EAGL batteries looks to have its own BMS; am I correct in thinking I will have to use their included charger rather than (simply) changing the onboard charger to lithium mode? The chemistry of the pack is LiFe PO4, for what it's worth.  I haven't torn anything apart yet (to diagram), so  I am not sure how the dash will interpret the AMP draw, but the kit I am looking at includes a dash mounted charge indicator.
      If anyone has completed a similar conversion, do you have any tips? Specifically, how did you remove the original batteries, and how did you secure the new ones? I am guessing that almost any change from the stock batteries would involve at least some modifications. Any tips would be appreciated, especially things I may have failed to consider. Thanks!
×
×
