I put my order in for differential a couple of days ago and I didn't buy any of these because when I told people 200.00 they didn't want them. But if some one wants one I can get it. Usually takes 20 days.You would still need to get your third lever that's about 100.00 for it.

LOCKING DIFFERENTIAL MECHANISM
ITEM NO. PARTS CODE PARTS NAME QTY
.
1 .02.6183,1-M8/05 LOCK NUT M8 2
2 .02.2842-M8/05 FLANGE NUT M8 1
3 .S800.03.01.07 RELEASE LEVER MOUNT 1
4.01.5787-M8x20/05 FLANGE BOLT M8x20 2
5 .JD.1082101 RUBBER COVER 1
6.TR1100.03.01.06A DIFFERENTIAL LOCKING HANDLE 1
7 .DLJ.REV-33 RELEASE LEVER 1
8 .DLJ.REV-36 SPACER 1
9 .01.70,1-M8x60/05 HHCS BOLT M8x60 1
10 .JD.1092004 LEVER MOUNT CABLE RETAINE 1

12 .01.5787-M6x12/05 FLANGE BOLT M6x12 2
13 .S800.03.01.0002 CABLE BRACKET 1

15 .TR1100.03.01.05A FRONT LOCKER CABLE 1
