09 joyner trooper t2 - Need some parts!
By
shady light, in Joyner UTV SxS Forum
-
-
Similar Forum Topics
-
Wanted: Trooper Axle Parts
I am interested in any old trooper axle parts you may have lying around. Please let me know if your want to sell them. Backstory: Hey everyone. Last trip out to moab I climbed a wall on poison spyder Mesa while 2 rzr xp1000's and three can am x3 xrc's watched me and didn't dare try. After doing it once I pulled around to show them it wasn't a fluke. One on the can am x3 xrc drivers just looked at me and said "that's steep". On the second try I spread the bell on the left rear axle. I made the climb but now the inner cage slips inside making a loud popping noise as twisting the boot. I mainly just need the inner bell but I am interested in anything you have.By 2scoops, in Joyner UTV SxS Forum
- 0 replies
- 79 views
-
Hey Guys!
Hey everyone! My name is Scott, and my wife, kids and I are in escrow on a home that is on 10 acres. After much back and forth trying to decide between getting a tractor or a side x side for working around the property, I finally narrowed it down to a side x side. My father has a 2018 Odes Dominator x4 Zeus, so I called him up to get his thoughts on it, as he uses it on his 12 acres out in Missouri quite a bit. While talking, he mentioned that he is thinking about selling his Odes, and buying a jeep to tow behind his motorhome, so we got to talking, and it looks like I'm buying it from him. Its a 2018 with 13 hours on it, break in just done, and all fluids just got changed. I look forward to learning more about the UTV world, and look forward to any input anyone can give me on the Odes brand of UTV. Thanks ScottBy Poriggity, in New Members Area
- 2 replies
- 84 views
-
Joyner trooper electric power steering for $200..
I made my own electric power steering for my Joyner trooper..I bought a steering column out of a 02 satern vue for $80 at a junk yard..then bought a wiring kit off of eBay for another $80. And made the steering arm...the wiring kit even came with a adjustable nob..By Tobie1987, in Joyner UTV SxS Forum
- 23 replies
- 1,693 views
-
I have a 2004 Joyner 1100cc need clutch cable fuel pump and fuel filter
I live in Utah and I can’t find parts hereBy Candn Garage Doors, in Joyner UTV SxS Forum
- 3 replies
- 162 views
-
Parts, Pieces, and Information for our Troopers & Joyners
Dealers - - - also see http://www.utvboard....dpost__p__16044 & http://www.utvboard....dpost__p__16045
No Limits Powersports in Arlington Texas - Contact Jarrad (Snowman6479). (817)695-1151 http://www.joyner-atv-utv.com/
Silver Bullet Motorsports in Yuma Arizona - Contact (silverbullet). (928) 344-2117 http://www.silverbul...otorsports.net/
Thin Air Powersports in Spring Creek Nevada - Contacts Tim (Anylizer) or Amanda (Long Track Lady) (775)753-8223 http://www.thinairpowersports.com/
McCoy Motorsports in Pikeville Kentucky - Contact Art (Art) (606)432-1556 http://www.tobefast....sa-c-63727.html
Mudslingers Motorsports, Alberta, Canada, Trevor Carson (780) 576-2860 cell: (780) 984-2711 http://www.mudslinge...website_006.htm
Joyner USA In Phoenix Arizona - Contact Brandon Deruiter Office (480) 882-9612 Email [email protected] Web site Joyner-usa.com
I also take suggestions for any and everyone!! parts & pieces from dealer in Germany http://www.utvboard.com/topic/3168-joyner-parts-and-all-chery-and-lj276-engine-parts/?p=18349 AIR FILTER K&N RU-1000, RC-4160, and another link
If you have the new 09 filter box, w/ Fram # CA-7764
ALTERNATOR BELT 14mmx 755mm replacement that works....Carquest #K040292
Alternator Belt - Checkers Auto Parts KO40292 - Exact Match
Battery, according to 2 scoops, Duralast 51-DL is the correct size.
OIL FILTERS
Troopers with Thread Size 20X1.5 MM can use:
WIX 51347, 51334 --- Napa 1347, 1334, PS1334 --- Fram PH6010A, PH3593A
Troopers with Thread Size 3/4X16 " can use:
Fram PH4967, Napa 1394 & Wix 5194 (slightly longer than original, Wix 51396 (even longer yet).
OIL COOLER See thread, http://www.utvboard....768-oil-cooler/
Oil Pressure Gauge Replacement
Zorro found some at his Local Marine Supply store
Sending Unit -- TeleFlex Morse Part # IA15001 0-80 psi, 240-33 ohm
Gauge -- TeleFlex Morse Part # 57903P 0-80 psi, 240-33 ohm
Manufactured by Veethree Elec. & Marine LLC
together cost aprox $80.00
Says it fits the existing hole perfectly Thanks Zorro
Plumber added this reference; http://www.spydertal...pressure-gauge/ which Crosses over to a Sierra part# 01858990
IMHO--I would move the the sender away from the exhaust manifold.
FUEL FILTER replacement, Fram Fuel Filter G4777
FUEL PUMP replacement, Bosch 0 580 254 910 According to Brostar, (Thank You!!)
http://www.ebay.com/itm/Hayg-OEM-Inline-Fuel-Pump-0-580-254-910-0580254910-New-/230568738342#vi-content (updated 05-2015)
PRE FILTER KNN-RC-4160-DK prefilter HEAD LIGHT REPLACEMENT Sylvania H5006 replaces the whole bulb, It works sooooo much better than the original. SPARK PLUGS NGK Iridium BKR5EIX-11, NGK 2387, NGK BKR7ES-11, Bosh 3311, Denso Iridium plug 5310 IK22
CV Boot Kit There appears to be a difference between inner and outer boots, I used a NAPA CVB6862340 for my outer rear, fit good but not tightly on the CV end, I held it on with Tyraps
Autozone part # 03606. Comes with bands and grease for $11.99, quick/split boot. K2181 95 Geo Metro $15.99
NAPA #686-2149 fits for the Troopers inner CV. It's a speck tight but only about 1/16".(Lenny)
Napa 686-2181 CV Boot from a 95 Geo Metro.
http://www.norrecind...tart=1&cat=1394 or
Norrec Industries then Application, then UTV, then look up joyner, they have them all
Polaris CV Boot Kit # 2203438, (PR-8061)
Also see CV boot for driveline? - UTV BOARD - Side X Side and UTV Forum
Valves shims are 25mm, Joyner shims start at 2.18 and increase in increments of .02 up to 2.80, The Honda shims come out of CB450s and GL1100s, start at 2.30 and increase in increments of .05
http://www.mawonline...gle/P137630.HTM
http://stores.ebay.c...&_sid=120606839
Master Electrical Switch Key
http://www.jegs.com/...oductId=1231908
http://www.pegasusau....asp?RecID=1467
Make your own, it's easy, I did, just in case mine breaks.
At the suggestion of one of our members, here's some info on the gas gauge sending unit.
3 ohms is full, 13 ohms is 3/4, 23 ohms is 1/2, 63 ohm is 1/2, 110 ohms is empty.
Electrical readings are: F=0.75v-98ma, 3/4=1.91v-82ma, 1/2=2.7v-71ma, 1/4=3.3v-62ma, 0=4.1v-52ma, E=5.0v-39ma
0 is top of red zone, E is bottom of red zone.
Manuals and Information
Trooper T2 weights, 380lb. on each front wheel, 480 lb. on left rear, 520 on right rear TOTAL = 1760 pounds
down load this and save it!!!!
Torque Values Select Your type of bolt at the top. http://www.engineers...bles/torque.htm
My Snorkel Made from a Sears ShopVac 7' Hose and the Extension Wand,
Oil Drain QuickOilDrainValve.com http://www.oildrainvalve.net/ez-oil-drain-valve-ez-103-12mm-1-25/ the best way to change oil, IMHO Kinarfi
Fram Sure Drain #SD3
Paint as recommended by Brostar: http://www.zynolyte..../rustmaster.asp
Supplier of parts in General
http://www.cxracing.com/default.aspx
http://www.jegs.com/
http://www.summitracing.com/
Pegasus Auto Racing Supplies - Home Page
TireRack.com
McMaster-Carr
Discount Hydraulic Hose.com
Tie Rod Dust Boot, Checker Auto#13566
Rod End / Heim Joint Seals , http://pitstopusa.co...-end-seals.html, thanks rocmoc
Ball Joint Rod Ends AKA Heim Joints
16 x2.0mm threat, 16mm ID, 21 mm thick,
I got mine at McMaster-Carr 4483T36
PTFE/Kevlar Insert, M16 x 2.0 x 40.mm shank, 21,966 lb static radial load capacity, 23°, $25.60 ea. or $204.80 for 8
http://www.vxb.com/page/bearings/PROD/Kit12360
http://www.vxb.com/page/bearings/PROD/Kit12960
14 Inch Tires That fit our Stock Wheels Note that the stock lug bolt pattern is 4 X 115
STEEL WHEELS http://www.utvboard....dpost__p__10804
JC Whitney for all Auto parts - Car, Truck, Jeep, Motorcycle & RV Parts
Interco Tires SSR-24R - INTERCO SSR Series Tire - Quadratec
Interco Tires SAM-12 - INTERCO Super Swamper TSL Tire - Quadratec
TSL Radial | Interco Tire
Maxxis Bighorn 2.0 AT26 X 11R 14
General Grabber AT2 27x8.50 R14 95Q 6PR OWL $90.10 http://ssl.delti.com.../GRABBERAT2.jpg
National Chaparral A/P 27x8.50 R14 95Q 6PR OWL $113.80 http://ssl.delti.com...ChaparralAP.jpg
Kumho Road Venture MT-834 27x8.50 R14 95Q 6PR OWL $110.30
Mastercraft COURSER A/T 27x8.50 R14 95Q 6PR OWL $87.00 http://ssl.delti.com...t/COURSERAT.jpg
Cooper Discoverer LT 27x8.50 R14 95Q 6PR OWL $99.60 http://ssl.delti.com...iscovererlt.jpg
Laramie Performer RV 27x8.50 R14 95Q 6PR OWL $100.70 http://ssl.delti.com...PerformerRV.jpg
ITP MUD LITE XTR 27-9-14 $87.99
ITP TERRACROSS R/T 26-9-14 $144.99
15 inch Wheels [Be sure to get the correct lug nuts, 12X1.5
Vision Wheel Inc Vision Wheel
ITP has one now also, getting info. ITP TIRES - The World's #1 ATV Aftermarket Tire & Wheel Source :: Holeshot
Non Trooper Info
u joints for joyner renegade are Spicer 5-1501X and Precision 391. They are American work great. graybeard9 Differential Bolts 40 28 to Full 25 96144A227• 8.33 1100 Trooper T2 ECU Wiring Diagram.pdf Joyner Trooper Differential Rebuild Kit .docBy Kinarfi, in Joyner UTV SxS Forum
- trooper parts
- trooper
- (and 1 more)
- 28 replies
- 67,360 views
-
-
