Learn How to Tune Your Can-Am


Recommended Posts

Hey there!

My name is Chrissy and I work at The Tuning School. I am posting about our new tuning courses for HP Tuners and Dynojet PowerCore for Can-Am tuning. We developed two courses to teach shops and enthusiast how tune their SXS. Check out the information below, and if you have any questions please feel free to reach out!

Get ready to unleash the potential power of your Can Am SXS using HP Tuners VCM Suite(and their BRP Cable), or Dynojet PowerCore woth your PV3.
This course is sold as a book and online course in one package. You receive both!
Learn how to navigate and use your chosen software option to create and load custom tunes to fit your preferences. Take it further with performing your own R&D, using our processes as your guideline. The sky's the limit with proven safe processes developed in house by The Tuning School.

Supporting late model Commanders, Defenders, and Mavericks; you can learn how to tune for aftermarket injectors and upgraded thermostats. In addition, use the concepts covered for turbo applications to adjust for larger turbo setups, as well as alternative fuels.

Build as many tunes as you need and gain confidence in troubleshooting issues while you’re out on the trails. Or give your weekend fun haver a little power bump.

This course was built for the shop and enthusiast in mind. Giving both the freedom to create custom tunes, while also better understanding how tuning works overall.


Can-Am Tuning using HP Tuners or Can-Am Tuning using Dynojet PowerCore

If you have questions you ask here or shoot us an email at [email protected]







TTS Full Black Hrz-01.png

Link to comment
Share on other sites

  • Alex changed the title to Learn How to Tune Your Can-Am

Join the conversation

You can post now and register later. If you have an account, sign in now to post with your account.
Note: Your post will require moderator approval before it will be visible.

Guest
Reply to this topic...

×   Pasted as rich text.   Paste as plain text instead

  Only 75 emoji are allowed.

×   Your link has been automatically embedded.   Display as a link instead

×   Your previous content has been restored.   Clear editor

×   You cannot paste images directly. Upload or insert images from URL.

 Share

  • Similar Topics

    • By porterpowered
      Hello everyone! I would appreciate any recommendations for a snow plow for our Hisun Vector. Nothing fancy, just something to plow our hunting cabin's driveway. I'm having difficulty finding something that fits. Thanks!
    • By Lionel
      I purchased a new Landmaster EV lithium. I have only had the vehicle for 5 days. From nearly the first day, it intermittently would not start, either forward or reverse. After waiting a few minutes, it will go in reverse, but not forward. After a few more minutes, it will go forward. This happened several times over three days, and then it had a bigger problem. It would not go forward at all, and I had to drive it in reverse for 400 feet. About 30 minutes later, it could go forward. I called the dealer and told them to come and get it. Does anyone out there have this model? Are you having similar problems?
    • By Kinarfi
      Dealers - - - also see http://www.utvboard....dpost__p__16044 & http://www.utvboard....dpost__p__16045
      No Limits Powersports in Arlington Texas - Contact Jarrad (Snowman6479). (817)695-1151 http://www.joyner-atv-utv.com/
      Silver Bullet Motorsports in Yuma Arizona - Contact (silverbullet). (928) 344-2117 http://www.silverbul...otorsports.net/
      Thin Air Powersports in Spring Creek Nevada - Contacts Tim (Anylizer) or Amanda (Long Track Lady) (775)753-8223 http://www.thinairpowersports.com/
      McCoy Motorsports in Pikeville Kentucky - Contact Art (Art) (606)432-1556 http://www.tobefast....sa-c-63727.html
      Mudslingers Motorsports, Alberta, Canada, Trevor Carson (780) 576-2860 cell: (780) 984-2711 http://www.mudslinge...website_006.htm
      Joyner USA In Phoenix Arizona - Contact Brandon Deruiter Office (480) 882-9612  Email [email protected]   Web site Joyner-usa.com

      I also take suggestions for any and everyone!!
      parts & pieces from dealer in Germany
      http://www.utvboard.com/topic/3168-joyner-parts-and-all-chery-and-lj276-engine-parts/?p=18349
      AIR FILTER K&N RU-1000, RC-4160, and another link
      If you have the new 09 filter box, w/ Fram # CA-7764
      ALTERNATOR BELT 14mmx 755mm replacement that works....Carquest #K040292
      Alternator Belt - Checkers Auto Parts KO40292 - Exact Match
      Battery, according to 2 scoops, Duralast 51-DL is the correct size.
      OIL FILTERS
      Troopers with Thread Size 20X1.5 MM can use:
      WIX 51347, 51334 --- Napa 1347, 1334, PS1334 --- Fram PH6010A, PH3593A
      Troopers with Thread Size 3/4X16 " can use:
      Fram PH4967, Napa 1394 & Wix 5194 (slightly longer than original, Wix 51396 (even longer yet).

      OIL COOLER See thread, http://www.utvboard....768-oil-cooler/

      Oil Pressure Gauge Replacement
      Zorro found some at his Local Marine Supply store
      Sending Unit -- TeleFlex Morse Part # IA15001 0-80 psi, 240-33 ohm
      Gauge -- TeleFlex Morse Part # 57903P 0-80 psi, 240-33 ohm
      Manufactured by Veethree Elec. & Marine LLC
      together cost aprox $80.00
      Says it fits the existing hole perfectly Thanks Zorro
      Plumber added this reference; http://www.spydertal...pressure-gauge/ which Crosses over to a Sierra part# 01858990
      IMHO--I would move the the sender away from the exhaust manifold.

      FUEL FILTER replacement, Fram Fuel Filter G4777

      FUEL PUMP replacement, Bosch 0 580 254 910 According to Brostar, (Thank You!!)
      http://www.ebay.com/itm/Hayg-OEM-Inline-Fuel-Pump-0-580-254-910-0580254910-New-/230568738342#vi-content (updated 05-2015)

      PRE FILTER KNN-RC-4160-DK prefilter
      HEAD LIGHT REPLACEMENT Sylvania H5006 replaces the whole bulb, It works sooooo much better than the original.
      SPARK PLUGS NGK Iridium BKR5EIX-11, NGK 2387, NGK BKR7ES-11, Bosh 3311, Denso Iridium plug 5310 IK22

      CV Boot Kit There appears to be a difference between inner and outer boots, I used a NAPA CVB6862340 for my outer rear, fit good but not tightly on the CV end, I held it on with Tyraps
      Autozone part # 03606. Comes with bands and grease for $11.99, quick/split boot. K2181 95 Geo Metro $15.99
      NAPA #686-2149 fits for the Troopers inner CV. It's a speck tight but only about 1/16".(Lenny)
      Napa 686-2181 CV Boot from a 95 Geo Metro.
      http://www.norrecind...tart=1&cat=1394 or
      Norrec Industries then Application, then UTV, then look up joyner, they have them all
      Polaris CV Boot Kit # 2203438, (PR-8061)
      Also see CV boot for driveline? - UTV BOARD - Side X Side and UTV Forum

      Valves shims are 25mm, Joyner shims start at 2.18 and increase in increments of .02 up to 2.80, The Honda shims come out of CB450s and GL1100s, start at 2.30 and increase in increments of .05
      http://www.mawonline...gle/P137630.HTM
      http://stores.ebay.c...&_sid=120606839

      Master Electrical Switch Key
      http://www.jegs.com/...oductId=1231908
      http://www.pegasusau....asp?RecID=1467
      Make your own, it's easy, I did, just in case mine breaks.

      At the suggestion of one of our members, here's some info on the gas gauge sending unit.
      3 ohms is full, 13 ohms is 3/4, 23 ohms is 1/2, 63 ohm is 1/2, 110 ohms is empty.
      Electrical readings are: F=0.75v-98ma, 3/4=1.91v-82ma, 1/2=2.7v-71ma, 1/4=3.3v-62ma, 0=4.1v-52ma, E=5.0v-39ma
      0 is top of red zone, E is bottom of red zone.


      Manuals and Information


      Trooper T2 weights, 380lb. on each front wheel, 480 lb. on left rear, 520 on right rear TOTAL = 1760 pounds

      down load this and save it!!!!
      Torque Values Select Your type of bolt at the top. http://www.engineers...bles/torque.htm
      My Snorkel Made from a Sears ShopVac 7' Hose and the Extension Wand,


      Oil Drain QuickOilDrainValve.com
      http://www.oildrainvalve.net/ez-oil-drain-valve-ez-103-12mm-1-25/
      the best way to change oil, IMHO Kinarfi
      Fram Sure Drain #SD3

      Paint as recommended by Brostar: http://www.zynolyte..../rustmaster.asp

      Supplier of parts in General

      http://www.cxracing.com/default.aspx
      http://www.jegs.com/
      http://www.summitracing.com/
      Pegasus Auto Racing Supplies - Home Page
      TireRack.com
      McMaster-Carr
      Discount Hydraulic Hose.com

      Tie Rod Dust Boot, Checker Auto#13566

      Rod End / Heim Joint Seals , http://pitstopusa.co...-end-seals.html, thanks rocmoc
      Ball Joint Rod Ends AKA Heim Joints
      16 x2.0mm threat, 16mm ID, 21 mm thick,
      I got mine at McMaster-Carr 4483T36
      PTFE/Kevlar Insert, M16 x 2.0 x 40.mm shank, 21,966 lb static radial load capacity, 23°, $25.60 ea. or $204.80 for 8
      http://www.vxb.com/page/bearings/PROD/Kit12360
      http://www.vxb.com/page/bearings/PROD/Kit12960

      14 Inch Tires That fit our Stock Wheels Note that the stock lug bolt pattern is 4 X 115
      STEEL WHEELS http://www.utvboard....dpost__p__10804
      JC Whitney for all Auto parts - Car, Truck, Jeep, Motorcycle & RV Parts
      Interco Tires SSR-24R - INTERCO SSR Series Tire - Quadratec
      Interco Tires SAM-12 - INTERCO Super Swamper TSL Tire - Quadratec
      TSL Radial | Interco Tire
      Maxxis Bighorn 2.0 AT26 X 11R 14
      General Grabber AT2 27x8.50 R14 95Q 6PR OWL $90.10 http://ssl.delti.com.../GRABBERAT2.jpg
      National Chaparral A/P 27x8.50 R14 95Q 6PR OWL $113.80 http://ssl.delti.com...ChaparralAP.jpg
      Kumho Road Venture MT-834 27x8.50 R14 95Q 6PR OWL $110.30
      Mastercraft COURSER A/T 27x8.50 R14 95Q 6PR OWL $87.00 http://ssl.delti.com...t/COURSERAT.jpg
      Cooper Discoverer LT 27x8.50 R14 95Q 6PR OWL $99.60 http://ssl.delti.com...iscovererlt.jpg
      Laramie Performer RV 27x8.50 R14 95Q 6PR OWL $100.70 http://ssl.delti.com...PerformerRV.jpg
      ITP MUD LITE XTR 27-9-14 $87.99
      ITP TERRACROSS R/T 26-9-14 $144.99

      15 inch Wheels [Be sure to get the correct lug nuts, 12X1.5
      Vision Wheel Inc Vision Wheel
      ITP has one now also, getting info. ITP TIRES - The World's #1 ATV Aftermarket Tire & Wheel Source :: Holeshot

      Non Trooper Info
      u joints for joyner renegade are Spicer 5-1501X and Precision 391. They are American work great. graybeard9
      Differential Bolts
      40 28 to Full 25 96144A227• 8.33
      1100 Trooper T2 ECU Wiring Diagram.pdf


      Joyner Trooper Differential Rebuild Kit .doc
