By Stan Morton
My 2018 XG-850-SL starter died yesterday. The old part number from Kubota is E7153-11732 which has been superceed by part # EG881-63010. I am looking for an aftermarket starter because the Kubota retail price for the starter starts at $550 and upwards toward $850. If anyone has gone down this road before and has found an aftermarket starter ~ please share with me. We own a ranch and this thing is used every single day and is sorely missed when it is down for maintenance. Kind Regards, ~ Stan
Earlier this year my battery was weak and I had to boost my mule to start it then I decided to remove the battery to check the fluid level which was very low, I set the levels and recharged the battery a few months later it did the same thing, so I had to boost it again then checked the voltage running was getting around 16 vdc ( which is too high) and fluid level was very low again and wouldn't hold a charge. Note: The battery was maybe 1-1/2 years old. Then I replaced the battery and checked the voltage running nothing changed I was only reading battery voltage it wouldn't increase with increased engine speed. I changed the voltage regulator with an aftermarket one, same thing not charging. I checked the alternator per the service manual which states .3 ohms or less it checks at .2 ohms and not shorted to ground. With the engine running I disconnected the alternator and it had around 22 vac idling and around 60 vac revving the engine, so I figured the regulator was bad so I replaced it with another new one (aftermarket) from a different company, again not charging only reading battery voltage. I did put the original voltage regulator on nothing changed still not charging. Using the manual wiring diagram did continuity checks going to the voltage regulator everything checks out OK. Now what am I missing?
New to owning a UTV and got myself a project one as my first one.
Changed out the clutch and clutch housing etc. as the UTV was having problems going up hills and getting up to speed but now in the process of putting it all back together it won't start. Also changed fan gears for shifter
Here's what I've found so far (apologies for the bullet points);
Motor will crank over and makes good turnover speed. If I use spark plug tester or ground to engine, no spark. At the connector to the ignition coil I get consistent 12v on the white wire and nothing at the black. Read in one of the posts that the 12v to the white wire should be intermittent when trying to get a spark at the plug? Tested ignition coil using a multimeter on resistance setting. Between two pins I get 0.46 ohms or thereabouts. Between either pin and spark plug boot I get somewhere around 16k ohms. Not really found a good video on testing these coils but think those are good readings. Checked fuses in fuse box and are all good. Fuel pump cycles on when I turn key to on position. I disconnected the ignition coil to remove the clutch etc. to get it out the way but don't think I've damaged anything in the process. Can anyone point me in the direction of what to try next? Been trying to use the manual but considering the test procedure for the ignition coil is for the wrong type of coil, it's not been too helpful. I've read on another post about checking the ECM the two pins with 12v etc so will take a look at that next but any ideas that could get this machine started again are welcome!
My gauge is working fine, but as it got low on gas and the gauge showed it as low, I filled it up but the gauge didn't come back up. Does it need to be restarted or anything to reset? Does it need to be driven a certain distance maybe or should it be instant?
By Greg Kilgore
We all know summer is hot inside the cabs of our SXS. So I've rigged up a couple of fans to help cool down the cab.
I didn't want to drill the fan's "support rails" into the ROPS (Roll Over Protection System), aka roll bars. So I used water clamps to hold them in place.
I just need to replace the wires I ran with bigger gauge. Then finish the wiring to switches, relays, and battery. But the hardest part. The actual mounting of the fans is complete. Also just in case anyone plans on doing this. I may have to only use 1 fan in the middle instead on 2. Due the the draw on the battery.
The fans are 12", 12V 80W. So I'm figured they were 6.7 amps apiece. Used the WAVe formula to get unknown values Watts=Amps*Volts then solve for unknown. I know the watts and volts from sticker on fan. So just used above formula to get amps. So a 7 amp fuse should be OK and a 10 amp fuse will be good.
So pulling 14 amps from the battery all day may be too much for the charging system to keep up with. And I haven't even installed the radio yet. So I will have to test and let you know.
See pics below.
